Торцевое уплотнение MG9
Описание Торцевое уплотнение MG9
Технические характеристики
Давление: ≤1,0 МПа
Скорость: ≤10м/с
Температура: -30℃~+180℃
Материал исполнения:
Вращающаяся часть: Графит/ Карбид кремния/ Карбид вольфрама
Неподвижное кольца: Керамика/ Карбид кремния/ Карбид вольфрама
Резиновые детали: НБР/ Епдм/ Витон
Пружина и металлические части: AISI304 / AISI316
Варианты неподвижных колец
|
d1 |
d6 |
d7 |
d14 |
d16 |
d3 |
d2 |
l1 |
l1K |
l1N |
l1S |
l5 |
l6 |
l17 |
l28 |
l29 |
|
10 |
17 |
21 |
11.0 |
24.60 |
19.6 |
13.0 |
53.0 |
32.5 |
40 |
34.0 |
1.5 |
4 |
7.5 |
6.6 |
9.0 |
|
12 |
19 |
23 |
13.5 |
27.80 |
21.6 |
15.0 |
53.0 |
32.5 |
40 |
34.0 |
1.5 |
4 |
7.5 |
6.6 |
9.0 |
|
14 |
21 |
25 |
17.0 |
30.95 |
24.0 |
18.0 |
54.5 |
35.0 |
40 |
35.5 |
1.5 |
4 |
9.0 |
6.6 |
10.5 |
|
15 |
– |
– |
17.0 |
30.95 |
25.0 |
19.0 |
54.5 |
– |
– |
35.5 |
– |
– |
9.0 |
– |
10.5 |
|
16 |
23 |
27 |
17.0 |
30.95 |
26.5 |
20.0 |
54.5 |
35.0 |
40 |
35.5 |
1.5 |
4 |
9.0 |
6.6 |
10.5 |
|
18 |
27 |
33 |
20.0 |
34.15 |
29.0 |
22.0 |
54.5 |
37.5 |
45 |
35.5 |
2.0 |
5 |
9.0 |
7.5 |
10.5 |
|
20 |
29 |
35 |
21.5 |
35.70 |
31.5 |
24.5 |
54.5 |
37.5 |
45 |
35.5 |
2.0 |
5 |
9.0 |
7.5 |
10.5 |
|
22 |
31 |
37 |
23.0 |
37.30 |
33.0 |
27.0 |
54.5 |
37.5 |
45 |
35.5 |
2.0 |
5 |
9.0 |
7.5 |
10.5 |
|
24 |
33 |
39 |
26.5 |
40.50 |
37.0 |
29.0 |
54.5 |
40.0 |
50 |
35.5 |
2.0 |
5 |
9.0 |
7.5 |
10.5 |
|
25 |
34 |
40 |
26.5 |
40.50 |
38.0 |
30.0 |
54.5 |
40.0 |
50 |
35.5 |
2.0 |
5 |
9.0 |
7.5 |
10.5 |
|
28 |
37 |
43 |
29.5 |
47.65 |
41.0 |
34.0 |
72.0 |
42.5 |
50 |
45.0 |
2.0 |
5 |
10.5 |
7.5 |
12.0 |
|
30 |
39 |
45 |
32.5 |
50.80 |
43.0 |
36.0 |
72.0 |
42.5 |
50 |
45.0 |
2.0 |
5 |
10.5 |
7.5 |
12.0 |
|
32 |
42 |
48 |
32.5 |
50.80 |
45.0 |
38.0 |
72.0 |
42.5 |
55 |
45.0 |
2.0 |
5 |
10.5 |
7.5 |
12.0 |
|
33 |
42 |
48 |
36.5 |
54.00 |
46.0 |
39.0 |
72.0 |
42.5 |
55 |
45.0 |
2.0 |
5 |
10.5 |
7.5 |
12.0 |
|
35 |
44 |
50 |
36.5 |
54.00 |
48.0 |
41.0 |
72.0 |
42.5 |
55 |
45.0 |
2.0 |
5 |
10.5 |
7.5 |
12.0 |
|
38 |
49 |
56 |
39.5 |
57.15 |
52.5 |
44.5 |
72.0 |
45.0 |
55 |
45.0 |
2.0 |
6 |
10.5 |
9.0 |
12.0 |
|
40 |
51 |
58 |
42.5 |
60.35 |
55.5 |
47.5 |
72.0 |
45.0 |
55 |
45.0 |
2.0 |
6 |
10.5 |
9.0 |
12.0 |
|
43 |
54 |
61 |
46.0 |
63.50 |
58.5 |
50.5 |
83.0 |
45.0 |
60 |
53.0 |
2.0 |
6 |
10.5 |
9.0 |
12.0 |
|
45 |
56 |
63 |
46.0 |
63.50 |
60.5 |
52.5 |
83.0 |
45.0 |
60 |
53.0 |
2.0 |
6 |
10.5 |
9.0 |
12.0 |
|
48 |
59 |
66 |
49.0 |
66.70 |
64.0 |
56.0 |
83.0 |
45.0 |
60 |
53.0 |
2.0 |
6 |
10.5 |
9.0 |
12.0 |
|
50 |
62 |
70 |
52.0 |
69.85 |
66.0 |
58.0 |
84.5 |
47.5 |
60 |
54.5 |
2.5 |
6 |
12.0 |
9.5 |
13.5 |
|
53 |
65 |
73 |
55.5 |
73.05 |
69.0 |
61.0 |
84.5 |
47.5 |
70 |
54.5 |
2.5 |
6 |
12.0 |
11.0 |
13.5 |
|
55 |
67 |
75 |
58.5 |
76.20 |
71.0 |
63.0 |
84.5 |
47.5 |
70 |
54.5 |
2.5 |
6 |
12.0 |
11.0 |
13.5 |
|
58 |
70 |
78 |
61.5 |
79.40 |
76.0 |
66.0 |
84.5 |
52.5 |
70 |
54.5 |
2.5 |
6 |
12.0 |
11.0 |
13.5 |
|
60 |
72 |
80 |
61.5 |
79.40 |
78.0 |
68.0 |
84.5 |
52.5 |
70 |
54.5 |
2.5 |
6 |
12.0 |
11.0 |
13.5 |
|
63 |
75 |
83 |
65.0 |
82.55 |
82.0 |
71.5 |
84.5 |
52.5 |
70 |
54.5 |
2.5 |
6 |
12.0 |
11.0 |
13.5 |
|
65 |
77 |
85 |
68.0 |
92.10 |
84.0 |
73.5 |
86.0 |
52.5 |
80 |
65.0 |
2.5 |
6 |
14.5 |
11.0 |
16.0 |
|
68 |
81 |
90 |
71.0 |
95.25 |
87.0 |
76.5 |
86.0 |
52.5 |
80 |
65.0 |
2.5 |
7 |
14.5 |
11.3 |
16.0 |
|
70 |
83 |
92 |
71.0 |
95.25 |
89.0 |
79.0 |
86.0 |
60.0 |
80 |
65.0 |
2.5 |
7 |
14.5 |
11.3 |
16.0 |
|
75 |
88 |
97 |
77.5 |
101.60 |
95.0 |
85.0 |
89.0 |
60.0 |
80 |
68.0 |
2.5 |
7 |
14.5 |
11.3 |
16.0 |
|
80 |
95 |
105 |
84.0 |
114.30 |
101.5 |
91.5 |
99.0 |
60.0 |
90 |
76.0 |
3.0 |
7 |
18.5 |
12.0 |
20.0 |
|
85 |
100 |
110 |
87.0 |
117.50 |
107.0 |
97.0 |
99.0 |
60.0 |
90 |
76.0 |
3.0 |
7 |
18.5 |
14.0 |
20.0 |
|
90 |
105 |
115 |
93.5 |
123.85 |
111.5 |
103.0 |
103.0 |
65.0 |
90 |
79.0 |
3.0 |
7 |
18.5 |
14.0 |
20.0 |
|
95 |
110 |
120 |
96.5 |
127.00 |
117.5 |
108.0 |
103.0 |
65.0 |
90 |
79.0 |
3.0 |
7 |
18.5 |
14.0 |
20.0 |
|
100 |
115 |
125 |
103.0 |
133.35 |
122.5 |
114.0 |
106.0 |
65.0 |
90 |
82.0 |
3.0 |
7 |
18.5 |
14.0 |
20.0 |
